When doing year-end maintenance on equipment this winter, don’t overlook the grain cart.

What not to overlook during a winter checkup

Growers have a little more time in winter to pull machines into the shop for maintenance.

It’s the perfect opportunity to give the whole farm fleet a thorough inspection to identify potential problems before they lead to a breakdown that will almost certainly occur when time is at a premium.

Kinze Manufacturing recently reminded producers that the grain cart should be among the machines brought in for a checkup. It published a list of maintenance items that includes things some may overlook.

Read Also

Barry Senft is stepping down as CEO of Seeds Canada after four years.. Photo: John Greig

Senft to step down as CEO of Seeds Canada

Barry Senft, the founding CEO of the five-year-old Seeds Canada organization is stepping down as of January 2026.

Here’s a summary of its recommendations, with a few of our own suggestions thrown in.

A good place to start is with a thorough cleaning to remove dirt and debris that might hide problems and promote corrosion. From there, it’s possible to do an overall inspection.

Look for cracks or damage to the side panels and frame. Structural defects like cracks or excessive rust could lead to failure when the cart is loaded.

Sand down minor rust spots and treat them with rust inhibitor and paint to slow rusting and extend the life of the cart. That will keep it looking good, too, and improve resale value.

There are many different spray bombs that will do the job. It’s even possible to get an autobody supply store to colour match the cart’s paint in a specially mixed spray can.

If the cart is equipped with a scale, check its accuracy. Kinze recommends doing at least five weight comparisons using another scale that has certified accuracy.

Check the electrical connections to the scale components. Clean them if necessary and apply a protective coating on exposed segments. Look for chafing and wear on wires that could cause a short circuit.

If the cart has wheels rather than tracks, Kinze recommends re-torquing the wheel nuts. If any nuts are loose, check the rim and studs for damage, such as cracks that might have occurred due to excessive flexing under load. Check tire pressures. Low air pressure in the tires can lead to overheating and premature failure.

Check the heel bearings too. They should be repacked with fresh grease periodically.

If the cart has tracks, check their alignment and belt tension to ensure even wear. Lubricate and inspect the bogies. Look for excessive wear or cracks on axle bolts and the main track frame.

On the driveline, look for slack or wear in components, and check oil levels in the gearbox. Inspect hydraulic hoses for fraying, wear or leaks. A simple blown hydraulic hose can shut down field operations for hours, so replacing those that look to be in poor condition now could save precious hours later. That would outweigh any value in trying to cut costs and squeeze a few more months of use out of them.

Check all driveline components for wear and cracks and check oil levels in gearboxes. Don’t forget to check the hitch and safety chains for stress cracks or damage that could cause failure. photo: Scott Garvey

Augers wear over time, causing internal flighting to become smaller in diameter, which reduces their performance. Replacing badly worn auger flighting will significantly improve the cart’s efficiency.

Specifically, look for wear where grain transitions from horizontal to vertical. These are the high-wear locations that slow unload times and put strain on other components.

Adjust drive belt tensions and inspect PTO shafts for cracks in the grooves and lubricate the slip joint in the shaft. Make sure all safety shields are in place. Too many farmers have been killed from PTO entanglements.

Don’t forget to check the condition of the tarp. If it’s electric, be sure it rolls easily and doesn’t bind.

There is also road safety to consider. Carts often make a lot of trips on public roads, so make sure slow-moving-vehicle signs are in place as well as reflective tape along with ensuring any lights or signals are working.

Finally, give the hitch and safety chains a final inspection to ensure the cart and tractor stay together. On older carts, cracks or severe rusting could lead to a failure under load, which would make for a very bad day.
